Kataloški broj:	MON2102FV
Šifra artikla:	1001081
Barkod:	1000000022834
Datoteke:	mon2102fv_upute.pdf
Opis:	MON 210 is a modern two-way optical node dedicated to applications in HFC networks. Node is equipped with automatic gain control (AGC). It responds to the optical power that is provided to the receiver input and accordingly adjusts amplification to keep the constant, pre-set output signal level. With added DUAL DF technology (two build in diplex filters) Your network is secured for future development and upgrades. This device meets all the standards related to RFoG technology, and it can be applied in PON networks thank to range of high quality lasers. The devices includes various DS and US bandwidths, various bandwidths in the return path are also available. We’ve prepared two versions of this device, one with exchangeable transmitter and another with integrated transceiver. Features: complex DOCSIS 3.1 solution, remote control and ingress protection, RF output level 112dBµV (CENELEC 42), Dual DF technology, DS band – 54-256..1218MHz, US band – 5..204MHz ECO mode with less power consumption, modular return path transmitters – OTBM, one fiber RFoG versions, based on BOSA lasers, low power consumption, universal solution for modern networks

Kategorije

Optički nod 1210...1650nm, fiksni atenuatori JXP, 5-204/87..1006MHz, 24-65Vac
